???displayArticle.abstract???
Noncanonical Wnt signals control morphogenetic movements during vertebrate gastrulation. Casein kinase I epsilon (CKIvarepsilon) is a Wnt-regulated kinase that regulates Wnt/beta-catenin signaling and has a beta-catenin-independent role(s) in morphogenesis that is poorly understood. Here we report the identification of a CKIvarepsilon binding partner, SIPA1L1/E6TP1, a GAP (GTPase activating protein) of the Rap small GTPase family. We show that CKIvarepsilon phosphorylates SIPA1L1 to reduce its stability and thereby increase Rap1 activation. Wnt-8, which activates CKIvarepsilon, enhances the CKIvarepsilon-dependent phosphorylation and degradation of SIPA1L1. In early Xenopus or zebrafish development, inactivation of the Rap1 pathway results in abnormal gastrulation and a shortened anterior-posterior axis. Although CKIvarepsilon also transduces Wnt/beta-catenin signaling, inhibition of Rap1 does not alter beta-catenin-regulated gene expression. Our data demonstrate a role for CKIvarepsilon in noncanonical Wnt signaling and indicate that Wnt regulates morphogenesis in part through CKIvarepsilon-mediated control of Rap1 signaling.
Figure 4. Rap1 Is Required for Wnt-8- and CKI-Mediated Axis Development(A) Expression of DN-Rap1 in Xenopus embryos causes an open yolk plug at the tail region of the presumptive secondary axis. mRNA of Wnt-8 (5 pg) or CKI (1 ng) was coinjected with DN-Rap1 (100 pg) into a single ventral cell of four-cell stage embryos. Embryos were scored and photographed at stage 18. Whole-mount in situ hybridization for Sox-2 expression was performed on stage 14 embryos. Black arrowhead, double axis; red arrowhead, gastrulation defect; bottom, scoring of stage 18 embryos.(B) Dorsal expression of DN-Rap1 alone causes a gastrulation defect in Xenopus embryos, whereas ventral expression does not affect gastrulation in the majority of embryos. DN-Rap1 RNA (500 pg) was injected into a single dorsal or ventral cell of four-cell stage embryos. Embryos were photographed at stages 18 and 30 as indicated. Black arrowhead, normal axis; red arrowhead, blastopore closure defect.(C) Disruption of Rap1 activity inhibits activin-induced convergent extension of animal cap. Convergent extension assays were performed on the Xenopus embryos, dorsally injected with RNA encoding GFP, DN-Rap1, or SIPA1L1(Cδ). Animal caps were photographed when the sibling embryos reached stage 18. The length-to-width ratios of the activin-treated animal caps were measured with MetaMorph software and are shown in the lower-right panel. Individual results for each animal cap are denoted by , and the average is shown at the top and denoted by — in the graph.(D) Xenopus embryos injected with Rap1 MO display a defect in gastrulation. Black arrowhead, normal axis; red arrowhead, defect in blastopore closure. The CE defect could be rescued by wild-type (WT) hRap1. Control MO (40 ng) or MOs against XRap1A (40 ng) and XRap1B (40 ng) were injected together into the animal cap of Xenopus at the one-cell stage. Two to four picograms of HA-tagged hRap1 were injected into two dorsal cells at the four-cell stage to rescue the Rap1-MO-caused defects. Only 5% (n = 99) of the embryos exhibit gastrulation defects after rescue. Red arrowhead, blastopore closure defect.
Figure 5. CKI and SIPA1L1 Are Upstream of Rap1(A) Dorsal expression of SIPA1L1(FL) or SIPA1L1(Cδ) alone in Xenopus embryos causes a gastrulation defect in 23% (n = 65) and 73% (n = 70) of embryos, respectively. Ventral expression does not induce an obvious phenotype in the majority of injected embryos (95% and 79% unaffected, n = 39 and 38, respectively). Four-cell stage embryos were injected with 1 ng of RNAs encoding SIPA1L1(FL) or SIPA1L1(Cδ) and photographed at stages 18 and 30. Black arrowhead, normal axis; red arrowhead, blastopore closure defect.(B) SIPA1L1(Cδ) but not SIPA1L1(FL) inhibits gastrulation at the presumptive secondary axis. (i) Uninjected control. (ii–iv) Xenopus four-cell stage embryos were injected dorsally with mRNA encoding (ii) CKI (1 ng) + GFP (250 pg); (iii) CKI + SIPA1L1(FL) (250 pg); and (iv) CKI + SIPA1L1(Cδ) (250 pg). (v) CKI + SIPA1L1(Cδ, mtGAP) (250 pg). In situ hybridization for Sox-2 expression was performed in stage 15 embryos. Black arrowhead, double axis; red arrowhead, gastrulation defect. Scoring data of stage 18 embryos are shown in the lower-right panel.
Choi,
Rap2 is required for Wnt/beta-catenin signaling pathway in Xenopus early development.
2005, Pubmed,
Xenbase
Choi,
Rap2 is required for Wnt/beta-catenin signaling pathway in Xenopus early development.
2005,
Pubmed
,
Xenbase Christian,
Interactions between Xwnt-8 and Spemann organizer signaling pathways generate dorsoventral pattern in the embryonic mesoderm of Xenopus.
1993,
Pubmed
,
Xenbase Crawford,
Germline polymorphisms in SIPA1 are associated with metastasis and other indicators of poor prognosis in breast cancer.
2006,
Pubmed Eide,
The circadian regulatory proteins BMAL1 and cryptochromes are substrates of casein kinase Iepsilon.
2002,
Pubmed Essner,
Kupffer's vesicle is a ciliated organ of asymmetry in the zebrafish embryo that initiates left-right development of the brain, heart and gut.
2005,
Pubmed Essner,
Mesendoderm and left-right brain, heart and gut development are differentially regulated by pitx2 isoforms.
2000,
Pubmed
,
Xenbase Fanto,
Nuclear signaling by Rac and Rho GTPases is required in the establishment of epithelial planar polarity in the Drosophila eye.
2000,
Pubmed Franke,
Sequential regulation of the small GTPase Rap1 in human platelets.
2000,
Pubmed Gao,
Identification of casein kinase I substrates by in vitro expression cloning screening.
2000,
Pubmed Gao,
Human papillomavirus type 16 E6-induced degradation of E6TP1 correlates with its ability to immortalize human mammary epithelial cells.
2001,
Pubmed Gao,
Casein kinase I phosphorylates and destabilizes the beta-catenin degradation complex.
2002,
Pubmed
,
Xenbase Gao,
The E6 oncoproteins of high-risk papillomaviruses bind to a novel putative GAP protein, E6TP1, and target it for degradation.
1999,
Pubmed Gietzen,
Identification of inhibitory autophosphorylation sites in casein kinase I epsilon.
1999,
Pubmed Habas,
Wnt/Frizzled activation of Rho regulates vertebrate gastrulation and requires a novel Formin homology protein Daam1.
2001,
Pubmed
,
Xenbase Habas,
Coactivation of Rac and Rho by Wnt/Frizzled signaling is required for vertebrate gastrulation.
2003,
Pubmed
,
Xenbase Harland,
In situ hybridization: an improved whole-mount method for Xenopus embryos.
1991,
Pubmed
,
Xenbase Heisenberg,
The function of silberblick in the positioning of the eye anlage in the zebrafish embryo.
1997,
Pubmed Heisenberg,
Silberblick/Wnt11 mediates convergent extension movements during zebrafish gastrulation.
2000,
Pubmed Jopling,
Fyn/Yes and non-canonical Wnt signalling converge on RhoA in vertebrate gastrulation cell movements.
2005,
Pubmed Keller,
Shaping the vertebrate body plan by polarized embryonic cell movements.
2002,
Pubmed Kimura-Yoshida,
Canonical Wnt signaling and its antagonist regulate anterior-posterior axis polarization by guiding cell migration in mouse visceral endoderm.
2005,
Pubmed Klein,
CKIepsilon/discs overgrown promotes both Wnt-Fz/beta-catenin and Fz/PCP signaling in Drosophila.
2006,
Pubmed Knippschild,
The casein kinase 1 family: participation in multiple cellular processes in eukaryotes.
2005,
Pubmed Kühl,
The Wnt/Ca2+ pathway: a new vertebrate Wnt signaling pathway takes shape.
2000,
Pubmed Logan,
The Wnt signaling pathway in development and disease.
2004,
Pubmed Marlow,
Zebrafish Rho kinase 2 acts downstream of Wnt11 to mediate cell polarity and effective convergence and extension movements.
2002,
Pubmed
,
Xenbase Mashhoon,
Structure of the unliganded cAMP-dependent protein kinase catalytic subunit from Saccharomyces cerevisiae.
2001,
Pubmed McKay,
The casein kinase I family: roles in morphogenesis.
2001,
Pubmed McLeod,
The Rap GTPases regulate B cell migration toward the chemokine stromal cell-derived factor-1 (CXCL12): potential role for Rap2 in promoting B cell migration.
2002,
Pubmed Pak,
Regulation of dendritic spine morphology by SPAR, a PSD-95-associated RapGAP.
2001,
Pubmed Park,
Sipa1 is a candidate for underlying the metastasis efficiency modifier locus Mtes1.
2005,
Pubmed Peters,
Casein kinase I transduces Wnt signals.
1999,
Pubmed
,
Xenbase Polakis,
Wnt signaling and cancer.
2000,
Pubmed Price,
CKI, there's more than one: casein kinase I family members in Wnt and Hedgehog signaling.
2006,
Pubmed Reya,
Wnt signalling in stem cells and cancer.
2005,
Pubmed Sakanaka,
Casein kinase iepsilon in the wnt pathway: regulation of beta-catenin function.
1999,
Pubmed
,
Xenbase Saneyoshi,
The Wnt/calcium pathway activates NF-AT and promotes ventral cell fate in Xenopus embryos.
2002,
Pubmed
,
Xenbase Sato,
Profilin is an effector for Daam1 in non-canonical Wnt signaling and is required for vertebrate gastrulation.
2006,
Pubmed
,
Xenbase Singh,
The high-risk human papillomavirus type 16 E6 counters the GAP function of E6TP1 toward small Rap G proteins.
2003,
Pubmed Sokol,
Analysis of Dishevelled signalling pathways during Xenopus development.
1996,
Pubmed
,
Xenbase Solnica-Krezel,
Conserved patterns of cell movements during vertebrate gastrulation.
2005,
Pubmed Strutt,
The role of RhoA in tissue polarity and Frizzled signalling.
1997,
Pubmed Strutt,
Planar polarity is positively regulated by casein kinase Iepsilon in Drosophila.
2006,
Pubmed Swiatek,
Regulation of casein kinase I epsilon activity by Wnt signaling.
2004,
Pubmed
,
Xenbase Tada,
Xwnt11 is a target of Xenopus Brachyury: regulation of gastrulation movements via Dishevelled, but not through the canonical Wnt pathway.
2000,
Pubmed
,
Xenbase Tahinci,
Distinct functions of Rho and Rac are required for convergent extension during Xenopus gastrulation.
2003,
Pubmed
,
Xenbase Tamada,
Activation of a signaling cascade by cytoskeleton stretch.
2004,
Pubmed Tao,
Maternal wnt11 activates the canonical wnt signaling pathway required for axis formation in Xenopus embryos.
2005,
Pubmed
,
Xenbase Veeman,
A second canon. Functions and mechanisms of beta-catenin-independent Wnt signaling.
2003,
Pubmed Vossler,
cAMP activates MAP kinase and Elk-1 through a B-Raf- and Rap1-dependent pathway.
1997,
Pubmed Wallingford,
Convergent extension: the molecular control of polarized cell movement during embryonic development.
2002,
Pubmed
,
Xenbase Wallingford,
Regulation of convergent extension in Xenopus by Wnt5a and Frizzled-8 is independent of the canonical Wnt pathway.
2001,
Pubmed
,
Xenbase Westfall,
Wnt-5/pipetail functions in vertebrate axis formation as a negative regulator of Wnt/beta-catenin activity.
2003,
Pubmed Xu,
Vascular development in the retina and inner ear: control by Norrin and Frizzled-4, a high-affinity ligand-receptor pair.
2004,
Pubmed
