XB-LINE-14
Line Name: Xla.Tg(myl2:GFP)Mohun
| Summary |
|
| Synonym: |
MLC2:GFP |
| Species: |
Xenopus laevis |
| Background Strain: |
Xla.Inbred
|
| Paternal Line: |
Portsmouth X.laevis |
| Maternal Line: |
Portsmouth X.laevis |
| Description: |
3kb of X. laevis myl2 (myosin light chain, also known as MLC2) driving GFP (variant mt5). Promoter sequence is NCBI AY219706. Select the best fluorescing animals at NF stage 35 & 36, monitor to NF stage 45. |
| Phenotype Description: |
GFP in ventricular chamber / heart myocardium, and interhyoid facial muscle. |
| Color Morph: |
pigmented |
| Breeding Type: |
OUTBRED (Isogenic)
|
| Lab of Origin: |
Mohun Lab |
| Line Type: |
Transgenic |
| Mutated Gene(s): |
|
| MTA Required: |
Yes
|
| Public: |
Yes
|
| Catalog Number: |
EXRC RRID tbd |
|
Cardiac-restricted expression of the MLC2::GFP transgenic line of Xenopus laevis.
A-E: The onset of cardiac fluorescence in a MLC2::GFP embryo can be detected faintly at stage 31 and is then more easily observed during heart looping stages. A: Ventral view of the heart-forming region at stage 31, anterior is to the top. B: Stage 33. C: Stage 36. D: Stage 41. E: Stage 46. F-I: Left lateral views showing the early detection of GFP in the heart. F, G: Bright field view and detail view of fluorescence at stage 31. H, I: Comparable images at stage 33. J-N: The GFP emission is restricted solely to the heart myocardium and is absent from all skeletal and smooth muscle. Images taken at stage 46. J, K: Bright field and fluorescence images of a left lateral view of the tadpole head and trunk. L: Left lateral detail of heart fluorescence. M, N: Bright field and fluorescence images of the ventral trunk. All images presented are of the same transgenic animal. H, heart; OT, outflow tract; A, atria; V, ventricle.
|
|
Cardiac expression of the MLC2::GFP transgenic line during larval development.
A-D: Detail ventral views of GFP fluorescence in the beating heart during larval stages. A: Stage 45. B: Stage 48. C: Stage 50. D: Stage 53. The GFP signal intensity increases in brightness to stage 48, but then Xanthophore pigment cells migrate over the pericardium to obscure the heart myocardium. The yellow sphere to the right posterior side of the heart is the gall bladder. E-H: Fluorescence images of the ventral head and trunk at the same stages. I-L: Bright field images of the ventral head and trunk. H, heart.
|
| Stock Center |
RRID |
Generation |
DOB |
# Males |
# Females |
Availability |
Mutant Details |
|
No availability, contact the Lab of Origin for information about this Xenopus line or strain. Articles using these frogs are listed on the Attribution Tab.
|
